Track Roller Assy For CAT317 CAT318 CAT319 CAT321 CAT325 CAT329

CAT329 Track Roller Bottom Roller Crawler Roller 8E-5032 I InScoremachinery

Definition: What is track roller, and what’s the role of track roller for an earthmoving equipment?

Track Roller is also called lower roller or bottom roller, which is designed to carry the majority of the excavators weight and dynamic forces through the tracks, and onto the ground.



Maintainence: How to prolong the lifespan of track roller?

The best way is to check on a regular basis, moreover It is strongly suggested replacing all the bottom rollers on one side. If only one roller per side is changed, then as the new roller may be slightly larger in diameter it will carry a higher load and have a shorter life:

ü Increase the point loadings of less worn rollers, thereby increasing peak ground bearing pressure.

ü Accelerate track wear.

ü Increase the likelihood of de-tracking and subsequent damage to tracks.

ü Increase the load on the track motor and gearbox.



Other info to share:

Track roller cannot be immersed in mud for a long time. After working, you should drive walking motor to get rid of dirt and gravel. In winter, should keep Track roller dry because there is a floating seal between the outer roller of Track roller and the shaft. If in water, it would freeze at night. When the excavator is walking the next day, the floating seal is in contact with ice to cause oil spill. When Track roller is damaged, can cause many faults, such as walking deviation, walking weakness and so on.

Description

BRANDMAINSTREAM MODELS
ATLAS-COPCOROC F6ROC D7ROC F9ROC L8ROC301



CATERPILLARE70BE110E120BE215E235E307E311E312E322
E180E240E200BE320E323E300E300BE330E325
E345







CASECX210CX290CASE300CASE450CASE650CASE8800CASE7700

CNH-FIAT NEW HOLLANDAD7FL4FL6D80




CHETRAT9T11T15T20T25T35T40

ChTZ T170








DOZERD20D30D31D37D39D41D45D50D51
D53D58D60A-8D61EX-12D61EX-15D61EX-23D65EX-12D65EX-15D68
D75D80D85ESS-2D150D155D275D355D375D475
D2D3CD4ED4HD5CD5KD6DD6HD6K
D6MD6GD7HD7RD7GD8HD8KD8ND8L
D8TD9ND9RD9TD9LD10ND10TD11ND11R
D135AFT150FT155FT165PL83PL87SD5KSD6NSD6NLGP

SD7NSD7KSD8N





DAEWOODH55DH200DH220DH280DH360LCDH420LCDH500LC

DOOSANSOLAR225LCVSOLAR340LCVSOLAR420LCVSOLAR470LCVSOLAR500LCVSOLAR520LCVDX300

DRESSTATD 10TD14TD15TD20TD25



FIATFD9AD7AD14FD1707DAD12HD6

FIAT-HITACHIFH120FH130FH150FH200FH220FH270FH300

KOMATSUPC30PC40PC45PC60PC75PC100PC120PC150PC200
PC220PC300PC350PC400PC500PC650PC850PC1250PC2000
HITACHIEX30EX40EX60EX100EX120EX200EX220EX270EX300
EX400EX600EX700EX800UH053UH07UH081UH082UH083
HYUNDAIR110R130R150R200R360R480R210R290
JCBJS70JS75JS110JS130JS160JS180JS200JS205JS220
JS240JS260JS300JS305JS330JS460


JOHN DEEREJD450HJD550HJD650JJD750JJD850J



KOBELCOSK40SK60SK100SK120SK200SK220SK04-2SK07SK210-9
SK07N2SK09SK12SK14SK 250SK270SK300SK310SK330
SK350SK380SK400SK480SK450



KATOHD140HD250HD400HD450HD550HD700HD820HD850HD880
HD900HD1220HD1250





LIEBHERRR904R914R944R954R964R994PR724PR734PR751
MITSUBISHIMS110MS120MS140MS180




SANYSANY75SANY90SANY310SANY365SANY485SANY650


SUMITOMOSH70SH100SH120SH160SH200SH260SH265SH280SH300
SH340LS2650LS2800LS3400LS4300



SAMSUNG H.I.MX8SE200SE210SE280MX292SE350


VOLVOEC55EC130EC150EC200EC210EC240EC290EC350EC360
EC480







WIRTGENVogele Super 1600-1/2/3Vogele Super 1800-1/2/3Vogele Super 1900-1/2/3Vogele Super 2100-1/2/3
